Fuel
Tanks & Accessories - 1969-1977 Standard Beetles
The fuel tank system that VW came up with in 1969 changed the
overly complicated breathing system of the 1968 models and for
the most part didn't change it again through the end of German
production. In 1975 when Fuel Injection was added, the fuel tank
was changed to accommodate a return line and increase the size
of the outlet line - this fuel tank is not available new but the
69-74 tank can be modified.
Fuel Tanks
A
illus
Year
Item
#
Price
Order
A
68-74
113201075AD
$219.95
Fuel Tank Retainer Kits
B
C
illus
Year
Item
#
Price
Order
B
49-69
111201635
$16.95
/ set of 4
C
70-79
113201635
$16.95 / set of 4
Fuel Tank Retainer Hardware
D
E
illus
Year
Item
#
Description
Price
Order
D
49-79
N102404
bolt
$.30
E
49-79
N120082
lock washer
$.15
Fuel Tank to Body Seal
F
illus
Year
Item
#
Price
Order
F
61-79
111-621B
$11.95
Fuel Tank Outlet Kit
G
illus
Year
Item
#
Price
Order
G
62-74
131298221
$9.95
Fuel
Hose
H
I
illus
Year
Item
#
Description
Price
Order
H
46-74
N203551
Carb,
5mm - cloth covered - German
$14.95
I
75-77
N203571
FI, 7mm - cloth covered - German
$14.95
Fuel
Tank Filter Screen
J
illus
Year
Item
#
Price
Order
J
56-74
111209147A
$9.95
Fuel
Tank Filter Screen Sealing Ring
K
illus
Year
Item
#
Price
Order
K
46-74
111209139
$1.00
Fuel
Tank Outlet Pipe Sealing Ring L
illus
Year
Item
#
Price
Order
L
46-74
311201235
$1.50
Fuel
Line Through Chassis Collars
(Seals)
M
N
illus
Year
Item
#
Description
Price
Order
M
10/52-74
111-189A
carbureted models
$5.95
pr.
N
75-77
111209189D
fuel injected - two lines
$2.95
Fuel
Tank Sending Unit Seals
O
illus
Year
Item
#
Price
Order
O
62-77
113919133
$9.95
Fuel
Tank Sending Units
P
illus
Year
Item
#
Description
Price
Order
P
68-77
113919049D
Electric
- German VDO
$99.95
P
68-77
113919049DRP
Electric - Reproduction
$49.95
'T'
Connector to Fuel Tank Hose
Q
illus
Year
Item
#
Price
Order
Q
68-77
N203551-8
$10.95
Breather
/ Fuel Hose
R
illus
Year
Item
#
Description
Price
Order
R
--
N203532
3.5mm
/ German
$14.95 / meter
Fuel
Filler Vent T
S
illus
Year
Item
#
Price
Order
S
68-77
113201157
$7.95
Fuel
Filler Vent T T
illus
Year
Item
#
Price
Order
T
68-77 STD
113201179A
$10.95
Fuel
Filler Neck Hose Clamp
U
illus
Year
Item
#
Price
Order
U
68-79
111201159B
$6.95
Fuel
Filler Neck Hose Seals
V
illus
Year
Item
#
Price
Order
V
68-77
113201215
$2.95
ea
Fuel
Filler Neck Hose
W
illus
Year
Item
#
Price
Order
W
68-77
311201219A
$19.95
Gas
Cap Gaskets
X
Gas
Cap Gaskets
illus
Year
Item
#
Description
Price
Order
X
68-72
111115487
60mm
$1.95
Gas
Caps
YZ 12
illus
Year
Item
#
Description
Price
Order
Y
68-72
113201551A
German
$14.95
Z
68-72
113201551ALK
Locking
$19.95
1
72-77
321201551G
--
$11.95
2
72-77
321201551H
Locking
$49.95
Fuel
Filler Neck Seal
3
illus
Year
Item
#
Price
Order
3
72-77
111809599A
$24.95
Fuel
Tank Sending Unit Block-Off Plate
4
illus
Year
Item
#
Price
Order
4
--
211201105
$6.95
